LOGIC GATES
A
B
C
0
0
0
1
0
1
0
1
1
1
1
1
OR
The OR function is fulfilled if at least one of its input conditions are true.
From the LADDER OR Diagram it should be seen that EITHER I 0.0 OR I 0.1 CAN BE AT STATUS 1 BEFORE Q 10.0 = STATUS 1
A OR B = C
